Stage Roof System
The 24m*16m*8m Stage Truss System is based on standard Truss 760*520mm rectangle truss as beam and 400*400mm Square Truss as pillars. It is quick and easy to assemble, saving building time and labour cost. when transport we can put 400mm truss into 520*760mm truss. It can help you save much shipping fee.
Item No :
JY-TRUSS22Order(MOQ) :
1piecePayment :
30% deposit, 70% balance before delivery goods.( standard goods)Product Origin :
ChinaColor :
Sliver / BlackShipping Port :
Gunagzhou/Foshan/ShenzhenLead Time :
3-15 working daysWeight :
1350kgStage Truss System
1. This kind of Stage Truss System is widely used in market for hanging LED screen, lights and speakers, they can used in show, exhibition, performance, advertisement, outdoor celebration and so on.
2. the roof stage truss is easy to assembly with the box corner system
3. we are professional manufacturer of truss, making-up, setting-up, according to your desire, we can design the most suitable exhibition truss for you.
With dimensions of 24 meters long, 16 meters deep, and 8 meters high, this frame provides ample space for mounting lighting fixtures, sound equipment, and other stage elements.
| Item | stage truss system for sale |
| Pillars | 400*400mm square truss |
| Beam | 520*760mm Heavy Duty Truss |
| Dimensions | 18m |
| Loading capacity | 18m span with 1200kg laoding capacity |
| Total weight | about 1500kg |
| Transporation volume | about 16 square meters |
| Color | Sliver / Black |
| Production time | 10-15days |
| HS code | 7610900000 |
Being modular means that this system is composed of standardized sections that can be easily connected together to create various configurations, allowing for flexibility in design and size.
When you want to set up a truss structure, you need think about your site limitation. indoor or outdoor? what size truss strcuture you want to set up? how long beam truss? how high pillar truss? Goal post shape ? Square shape? or Rectangle shape truss structure? with top roof or without top roof. Please let us know your requirements then our design team can help you design your draft.
We can offer different shape, size truss for your different event needs.
| Product Name | Spigot Truss, Bolt Truss, Global Truss, Thomas Truss, Roof Truss , Pre-Rigging truss, Stage Truss; Box truss; light truss stand; Layer truss; Aluminum truss; Lifting System |
| Truss Type |
Spigot Truss: 100x100mm, 220x220mm, 290x290mm, 400x400mm,520x520mm, 760*520mm,1010*610mm Etc Bolt Truss: 12''x12'' screw truss; Thomas Truss; Tomcat Truss; 400x400mm, 520*520mm Etc |
| Length | 0.5m/1.0m/1.5m/2.0m/2.5m/3.0m/3.5M; 1FT/2FT/3FT/4FT/5FT/6FT/8FT/10FT/12FT |
| Raw Material | Aluminum Pipe: EN AW 6082-T6/ 6061-T6 ; Welding rod: AlcoTec 5356/4043 |
| Truss Surface | Original Silver; Or Customized Color By Powder Coating & Anodizing; |
| Certificate | ISO 9001, ISO 3834; TUV Certificate, EN1090-1; EN1090-3; SGS certified |
| Section Shape | Ladder truss, Triangle truss , Square truss, Circular truss, Rectangle truss |
| Package | Carton, Trolley; Flight Case; Pallet |
| Application | Concert, Wedding, Ninja Warrior, Exhibition, Events for outdoor and indoor |
More products for your reference. if you nee more products information please contact us directly. will send catalogue and price list to you soon.
The Stage Roof Truss Structure is composed of multipurpose Box Truss 290*290mm as beams and pillars with right load-bearing capacity. It is modular and versatile, quick and easy to assemble and saving building time and labour cost. Besides, you can also extend it to be Pyramid roof, Arc Roof, ect.
Read More
Outdoor Event Lighting Truss available for rental and It is composed of multipurpose Box Truss as beams and pillars with right load-bearing capacity. Aluminum truss is widely used in all kinds of event and stage, it provides structure to hold lightings and other stage equipments. it is also the outdoor stage system main frame.
Read More
Outdoor Stage Sound Truss System 8m long, 5m deep and 5m high with 2 speaker wings tower 2m wide. Sound Truss System provides a substantial and adaptable platform for any large-scale event. Its impressive dimensions allow for expansive stage design and a wide array of lighting and sound equipment placement.
Read More
The Outdoor custom Screw Truss sizes 6m wide, 6m deep and 6m high bolt truss system offering a robust and adaptable solution for both temporary and semi-permanent lighting and staging needs.
Read More
Truss Size:12*8*7m Outdoor Roof Truss System. The Stage Roof Truss design offering a stable and versatile platform for various events and performances. The truss system provides structural support for the platform and roof, ensuring safety and stability.
Read More
This is Bolt Truss 300*30mm system with custom sizes 6m long, 4m wide and 5m high. ItsTruss Beam is 300 x 300mm and Pillars are 300x300mm Bolt connection, so easy to install.
Read More
Round Roof Wedding Truss compression ring structure uses Curved Roof Trusses to shape Circular Trusses and is lifted by a system of four Ground Support Lifting Towers.
Read More
Many customers prefer to suspend lighting fixtures from Circular Trusses for their interior design needs. Some clients also opt to use columns to support these circular truss.
Read More
