Stage Roof System
Boost your event production with our Aluminum Alloy Arc Roof Truss System. Featuring a 7m height and dedicated 2m speaker wings, this durable, mobile stage assembly is perfect for outdoor concerts and professional festivals.
Item No :
JY-TRUSS29Order(MOQ) :
1piecePayment :
30% deposit, 70% balance before delivery goods.( standard goods)Product Origin :
ChinaColor :
Sliver / BlackShipping Port :
Gunagzhou/Foshan/ShenzhenLead Time :
3-15 working daysProfessional Event Aluminum Arc Roof Truss System
Elevate your outdoor performances with our premium Aluminum Alloy Mobile Stage Roof. Engineered for durability and rapid assembly, this arc-style truss system provides a massive covered area and a professional aesthetic for concerts, festivals, and corporate events.
Key Technical Specifications:
Dimensions: Max. size Arc roof system 18*18*9m with 400*400mm square truss.
Height: 9m clearance, providing ample room for complex lighting rigs and backdrops.
Integrated Speaker Wings: Includes two 3m wide side wings specifically designed for flying line-array speaker systems, ensuring clear sound distribution without obstructing the main stage.
Material: High-grade 6061-T6 Aluminum Alloy for maximum load-bearing capacity and corrosion resistance.
Features at a Glance:
Arc Roof Design: Optimized for water drainage and superior structural integrity compared to flat-roof systems.
Modular Portability: The lightweight aluminum components are easy to transport and assemble, making it the ideal choice for mobile touring.
Versatile Mounting: Pre-engineered to support heavy-duty stage lighting, LED screens, and professional audio equipment.
Safety First: Built to international standards with reinforced pillar supports and stabilizing outriggers.
We can offer different shape, size truss for your different event needs.
| Product Name | Spigot Truss, Bolt Truss, Global Truss, Thomas Truss, Roof Truss , Pre-Rigging truss, Stage Truss; Box truss; light truss stand; Layer truss; Aluminum truss; Lifting System |
| Truss Type |
Spigot Truss: 100x100mm, 220x220mm, 290x290mm, 400x400mm,520x520mm, 760*520mm,1010*610mm Etc Bolt Truss: 12''x12'' screw truss; Thomas Truss; Tomcat Truss; 400x400mm, 520*520mm Etc |
| Length | 0.5m/1.0m/1.5m/2.0m/2.5m/3.0m/3.5M; 1FT/2FT/3FT/4FT/5FT/6FT/8FT/10FT/12FT |
| Raw Material | Aluminum Pipe: EN AW 6082-T6/ 6061-T6 ; Welding rod: AlcoTec 5356/4043 |
| Truss Surface | Original Silver; Or Customized Color By Powder Coating & Anodizing; |
| Certificate | ISO 9001, ISO 3834; TUV Certificate, EN1090-1; EN1090-3; SGS certified |
| Section Shape | Ladder truss, Triangle truss , Square truss, Circular truss, Rectangle truss |
| Package | Carton, Trolley; Flight Case; Pallet |
| Application | Concert, Wedding, Ninja Warrior, Exhibition, Events for outdoor and indoor |
Q1: What are the dimensions and speaker wing size can work?
A: The Truss Design can make 10*8*7m/ 12*10*7m/ 12*8*7m and Max. 16*16*7m two integrated 2m-wide speaker wings specially designed for line array speakers.
Q2: Is this system suitable for outdoor use and what certifications does it have?
A: Yes, it is built for outdoor events with corrosion-resistant aluminum and includes a full PVC roof canopy. The system is TUV-certified for safety and structural integrity.
Q3: How long does it take to assemble and what is included?
A: The modular design allows fast setup using the included towers, manual hoists, fibre slings, and all necessary connectors. Usually need 2 hours with 4 workers can be finished.
The Stage Roof Truss Structure is composed of multipurpose Box Truss 290*290mm as beams and pillars with right load-bearing capacity. It is modular and versatile, quick and easy to assemble and saving building time and labour cost. Besides, you can also extend it to be Pyramid roof, Arc Roof, ect.
Read More
Outdoor Event Lighting Truss available for rental and It is composed of multipurpose Box Truss as beams and pillars with right load-bearing capacity. Aluminum truss is widely used in all kinds of event and stage, it provides structure to hold lightings and other stage equipments. it is also the outdoor stage system main frame.
Read More
Outdoor Stage Sound Truss System 8m long, 5m deep and 5m high with 2 speaker wings tower 2m wide. Sound Truss System provides a substantial and adaptable platform for any large-scale event. Its impressive dimensions allow for expansive stage design and a wide array of lighting and sound equipment placement.
Read More
The Outdoor custom Screw Truss sizes 6m wide, 6m deep and 6m high bolt truss system offering a robust and adaptable solution for both temporary and semi-permanent lighting and staging needs.
Read More
4 Pillars Triangle Stage Roof system is mid sizes truss system, it's use for most of outdoor and indoor performance. Flexible structure depend your requirement. Fast install and reasonable design. Jiayi Lighting truss can make any size and special design Truss Structuref system for you.
Read More
This Stage Truss Roof System with 6 Ground Support Towers for outdoor events with 2 soundwings which can hang on Line array speakes or LED screen wall.
Read More
The stage truss curved roof structure is a fixed tower-based structure with 400*400mm Square Truss Segments. Different demensions are customed by simply changing the arches. PVC Cover on the top and sizes are optional.
Read More
The Black Color 14m*8m*7m Aluminum Curved Roof Stage Truss System with stage platform. The Curved Roof Stage Truss system consists of several components, including straight trusses, curved trusses, connectors, pins, and base plates. The straight trusses are used to form the main support structure, while the curved trusses create the desired curved shape.
Read More
